1 - 7
CHAPTER 1 Product Name & Specifications
5-10 Power Supply Voltage 12 VDC ± 5% (EBA-30/31/32/33/34/35)
(Use a power supply with 3A or higher capacity.)
24VDC ± 10% (EBA-34/35)
(Use a power supply with 1.6A or higher capacity.)
5-11 Current Consumption 12VDC
(1) In standby: 0.3A
(2) During operation: 1.6A (3A max.)
24VDC
(1) In standby: 0.2A
(2) During operation: 0.9A (1.6A max.)
5-12 Operating Environment (1) Operating temperature: 5 to 50ﾟC
(2) Storing temperature: -20 to 60ﾟC
(3) Relative humidity: 30 to 85% (no condensation)
(4) Installation: Install the unit indoors where it is not exposed to direct
sunlight.
5-13 Outer Dimensions Refer to the outline drawings for the configuration with SD3 stacker,
and without the stacker.
5-14 Weight (1) With SD3 stacker Approx. 2.5 kg
(2) Without SD3 stacker Approx. 1.0 kg
5-15 Mounting Horizontal mounting
Earthe the the sheet metal part of the unit
[NOTE] Unless otherwise specified, the general specifications of the EBA-3x series are measured
based on the following conditions:
(1) Power supply voltage: 12 VDC ± 0.1 V (19.9 to 12.1 V)
24VDC ± 0.2 V (23.8 to 24.2V)
(2) Temperature: 25
ﾟ
C ± 3
ﾟ
C (22 to 28
ﾟ
C)
(3) Relative humidity 40 to 65%
(4) Standard bill 20 Euro bill
