Jedia L3.0 - Front Panel Controls; LED Indicators (CLIP;LIM); Channel Volume Controls; Power and Protection LEDs

1. LED INDICATOR, CLIP/LIM
2. CHANNEL A, B
3. POWER, PROTECT LED
For the bridged mono, parallel, operation, volume control can be
adjusted by channel "A" adjust channel "B" to the counter clockwise.
4. POWER SWITCH
Provides power to the unit
1. To avoid loud switching noises, always switch on the power
amplifiers in an amplifier system after all other units have
been switched on.
2. At first, turn the volume fully counter clockwise, then with
approx 2~3 minutes be for switching off.
Turn "0dB" on LED indicator is normal operating.
Adjust volume when CLIP/LIM indicator is lighting continuously.
After switch on for approx 3 seconds. (in rush current)
2
Power LED on the channel A,B is turn on, when supplying
power to the amplifier.
1.󰼿LED메터,󰼿CLIP/LIM
운용시󰼿0dB󰼿LED가󰼿켜지는󰼿상태가󰼿정상󰼿출력이며󰼿CLIP/LIM󰼿LED가󰼿지속적
으로󰼿켜지는󰼿상황은󰼿과출력이니󰼿음량󰼿조정을󰼿재확인󰼿하십시오.
2.󰼿채널󰼿볼륨
각󰼿채널의󰼿음량을󰼿조절하는󰼿볼륨입니다.
브릿지모노,󰼿병렬󰼿운용시에는󰼿채널A󰼿볼륨으로󰼿음량󰼿조절할󰼿수󰼿있으며󰼿채널󰼿
B󰼿볼륨은󰼿반󰼿시계방향으로󰼿돌려󰼿놓고󰼿운용하십시오.󰼿
4.󰼿POWER󰼿SWITCH
3.󰼿POWER,󰼿PROTECT󰼿LED
F
RONT PANEL CONTROLS (전면󰼿각부의󰼿명칭과󰼿기능)
2
4
3
1
앰프에󰼿전원이󰼿공급되면󰼿채널A,󰼿B󰼿POWER󰼿LED가󰼿켜집니다.
전원󰼿스위치를󰼿켠󰼿후󰼿3초󰼿동안,󰼿앰프가󰼿과열󰼿또는󰼿스피커󰼿출력단에󰼿직류
전압이󰼿생기면󰼿보호회로가󰼿동작하여󰼿PROTECT󰼿LED가󰼿켜집니다.
※󰼿주의
NOTE
기기에󰼿전원을󰼿󰼿공급하는󰼿스위치󰼿입니다.
1.󰼿앰프의󰼿전원을󰼿켤때는󰼿주변󰼿음향기기들을󰼿먼저󰼿켠󰼿후에󰼿앰프의󰼿전원을
󰼿󰼿󰼿켜십시오.󰼿
2.󰼿앰프의󰼿전원을󰼿끌󰼿때는󰼿볼륨을󰼿반󰼿시계󰼿방향으로󰼿끝까지󰼿돌리고,󰼿2󰾝3분
󰼿󰼿󰼿정도󰼿기다린󰼿후󰼿방열󰼿판이󰼿식으면󰼿전원을󰼿꺼주시기󰼿바랍니다.󰼿
