Jedia L4.8 - Rear Panel Switches and Filters; Limiter and Ground Lift Switch; Mono Output and Filter Modes

4
5. CLIP/LIM, GROUND LIFT SWITCH
7. FILTER MODE
SUB WOOFER
FULL RANGE
This is for seriate operation per channel sub woofer, x-over
will not be operated.
Permissible adjustment of low cut.
Variable frequency(50~160Hz) by one volume.
Specification of filter -12dB/octave is for subwoofer speaker
mainly.
X-OVER(BI-AMP)
Permissible power supply to input "A" channel connect woofer
speaker to the "CHA" and connect high range speaker to the
"CHB".
It designed -24dB/octave variable frequency.(50Hz~2.5kHz)
LOW CUT
This is to protect speaker from damage by large ultra frequency
or blowing of voice coil, low it designed -12dB/octave variable
frequency.(10~200Hz)
6. MONO OUTPUT
Output connector supplying input CH"A, B" balanced output
connector.
It is convenient to use for sub woofer speaker only.
LIMITER SWITCH
This switch is for grounding between circuit ground and chassis
ground to avoid problems like a electrical potential difference.
When the audio signal drives the amps output circuit beyond
its power capability it clips flattening the peaks of the waveform.
The clip limiter detects this and quickly reduces the gain to
minimize the amount of overdrive limiting occurs only during
actual clipping. Each channel has its own clip limiter and you
can switch it on or off independently.
GROUND / LIFT
R
EAR PANEL CONTROLS (후면󰼿각부의󰼿명칭과󰼿기능󰼿)
5.󰼿CLIP/LIM,󰼿GROUND󰼿LIFT󰼿스위치
CLIP/LIM
출력󰼿신호가󰼿전력을󰼿초과하게󰼿되면󰼿일그러짐이󰼿발생하게󰼿됩니다.
이󰼿때󰼿리미터󰼿스위치는󰼿일그러짐이󰼿발생하지󰼿않은󰼿레벨로󰼿신호를
신속히󰼿줄여주게󰼿됩니다.
채널A,󰼿B󰼿각각󰼿독립적으로󰼿동작하게󰼿되며,󰼿실제로󰼿일그러짐이󰼿발생
했을󰼿때󰼿전면의󰼿CLIP/LIM󰼿LED가󰼿켜지게󰼿됩니다.
다이나믹󰼿레인지는󰼿+20dB입니다.
7.󰼿FILTER󰼿모드
FULL󰼿RANGE
각󰼿채널이󰼿분리되어󰼿운용할󰼿경우에󰼿사용되며󰼿SUB󰼿WOOFER,󰼿X-OVER
필터기능은󰼿동작되지󰼿않습니다.󰼿
그러나󰼿LOW󰼿CUT󰼿기능은󰼿조정이󰼿가능합니다.
GROUND/LIFT
회로의󰼿접지를󰼿샤시에󰼿접지󰼿시키는󰼿스위치이며,󰼿시스템󰼿구성시에󰼿
접지󰼿전위차로󰼿발생되는󰼿문제점들을󰼿해결할󰼿수󰼿있습니다.
SUB󰼿WOOFER
1개의󰼿볼륨에󰼿의해󰼿각󰼿채널별로󰼿필터󰼿주파수(50󰾝160Hz)를󰼿연속가
변할󰼿수󰼿있습니다.
필터󰼿특성은󰼿-12dB/Octave로󰼿설계되어󰼿있습니다.
주로󰼿저음󰼿스피커를󰼿구동하는󰼿앰프에󰼿사용되는󰼿기능입니다.
X-OVER(BI-AMP)
채널A󰼿입력에󰼿신호󰼿공급이󰼿가능합니다.
채널A󰼿출력에󰼿저음󰼿스피커,󰼿채널B󰼿출력에󰼿고음󰼿스피커를󰼿연결하십시오.
필터󰼿주파수(50Hz󰾝2.5kHz)를󰼿연속가변할󰼿수󰼿있으며󰼿필터󰼿특성은
-24dB/Octave로󰼿설계되어󰼿있다.
LOW󰼿CUT
가끔󰼿큰󰼿초저역󰼿주파수에󰼿의해󰼿스피커가󰼿손상되거나󰼿또는󰼿보이스코일
이󰼿열화󰼿되는󰼿것을󰼿방지하기󰼿위해󰼿저역󰼿차단󰼿필터를󰼿조정하여󰼿스피커를󰼿
보호할󰼿수󰼿있습니다.
필터󰼿주파수(10󰾝200Hz)를󰼿연속가변할󰼿수󰼿있으며󰼿필터󰼿특성은󰼿
-12dB/Octave로󰼿설계되어󰼿있습니다.
채널A,󰼿B󰼿입력에󰼿공급되는󰼿신호를󰼿조합하여󰼿출력되는󰼿콘넥터󰼿입니다.
출력󰼿콘넥터는󰼿바란스형이며󰼿이󰼿출력은󰼿통상󰼿스피커󰼿시스템에서󰼿저음󰼿
전용스피커󰼿구동󰼿앰프󰼿신호입력용으로󰼿사용하면󰼿편리합니다.
6.󰼿모노󰼿출력
