Jedia L4.8 - CONNECTIONS; Stereo (2-Channel) Speaker Connection

시스템󰼿연결그림은󰼿일반적인󰼿설치󰼿방법으로󰼿다음사항을󰼿주의󰼿하십시오.
1.󰼿스피커󰼿라인󰼿연결시󰼿앰프의󰼿전원󰼿스위치를󰼿꺼주십시오.
2.󰼿스피커󰼿결선은󰼿결선도를󰼿참고하여󰼿주십시오.
3.󰼿앰프는󰼿3개의󰼿모드(스테레오,󰼿브릿지󰼿모노,󰼿병렬)로󰼿전환󰼿시킬󰼿수󰼿있으며,󰼿
4.󰼿잘못된󰼿결선은󰼿스피커에󰼿치명적인󰼿손상을󰼿초래합니다.
앰프가󰼿동작󰼿중일때는󰼿전환하지󰼿마십시오.
스테레오󰼿방식
결선󰼿하십시오.
모드󰼿스위치를󰼿스테레오󰼿쪽으로󰼿전환하고󰼿스피커󰼿극성에󰼿주의하여
Wiring the following instructions describe the most common
ways to install your amplifier into a sound system.
1. First, turn off power switch befor connection.
2. Refer to wirning diagram for speaker connection.
(stereo, bridge-mono, Parallel)
3. L series amplifier maybe operated in one of three modes
4. JEDIA assumes no liability for damaged loads resulting from
careless amplifier use or deliberate over powering.
How to connect stereo(2-CHANNEL) MODE
connect the output wiring as shown.
To put the amplifier into stereo mode, first turn the amplifier off,
then slide the stereo-mono switch toward the left, and properly
C
ONNECTIONS (설치방법)
6
AMP MODE
B
G
A
INPUT
CH-A
ON
CH-B
Stereo
Bridged
Parallel
Stereo
CH-B
CH-A
CH-B
CH-A
CLIP/LIM
Parallel
Bridged
B/D
B/D
LIFT
OFF
GROUND
ON
1500W PER CH at 4ohms
AC 230V
/50Hz
4210W
MODEL NO:. L 6.0
STEREO POWER AMPLIFIER
MADE IN KOREA
STEREO
PROFESSIONAL AUDIO MIXER 8.4.4.2
TRIPAC Series or
STAGE PRO MIXER
TRIPAC
