Exterior Bulbs
Bulb Number
Low Beam/High Beam Headlamp H13
Front Park/Turn Signal/Side Marker Lamp 3757KA
Front Fog Lamp PSX24W
Center High Mounted Stop Lamp (CHMSL) LED Assembly (Serviced At Authorized Dealer)
Rear Tail/Turn/Stop Lamp 3157
Backup Lamp W16W (921)
License Lamp W5W
Replacing Exterior Bulbs
Headlamps
1. Raise the hood and locate the connector behind the
headlamp.
2. Reach into the engine compartment and pull the red
lock out at the green connector.
3. Remove green connector from back of bulb by pulling
straight back.
4. Twist the bulb to the left.
5. Pull bulb outward from assembly.
NOTE: These are halogen bulbs. Take care not to touch the
bulb with your fingers. Body oils from your fingers could
cause excessive heat buildup which reduces bulb life.
Fog Lamps
1. Access lamp through the lower fascia cutout.
2. Remove electrical connector from bulb.
3. Remove bulb from housing.
246 IN CASE OF EMERGENCY
