316 SERVICING AND MAINTENANCE
Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description
F01 70 Amp Tan – – Module Body Computer
F02 70 Amp Tan – –
Module Body Computer, Rear Distribution
Units
F03 –
30 Amp Pink with HID
Lamps
20 Amp Blue without
HID Lamps
– Supply Body Computer, HID Lamps
F04 – 40 Amp Tan – Brake Control Electronics Module
F05 – 40 Amp Tan – PTC Heater
F06 40 Amp Orange – – Starter Relay
F07 40 Amp Orange – – Rear Distribution Unit For Trailer Tow Usage
F08 – 30 Amp Pink – Supply For TCM, AGSM, Steering Control
F09 – – 7.5 Amp Brown ECM, TCM, Radiator Fan Control
F10 – – 20 Amp Yellow Horn
F11 – –
20 Amp Yellow – 1.4L
Gas & Diesel Engines
25 Amp Clear – 2.4 L
Engines/UREA
ECM/PCM/UREA Fuel Injectors
F14 – –
7.5 Amp Brown – Diesel
Engine
15 Amp Blue – Gas
Engine
Diesel Crankcase Heater
Gasoline LTR Cooling Pump
