GETTING TO KNOW YOUR INSTRUMENT PANEL 129
YELLOW INDICATOR LIGHTS
4WD Indicator Light — If Equipped
This light alerts the driver that the
vehicle is in the four-wheel drive
mode, and the front and rear
driveshafts are mechanically locked
together forcing the front and rear wheels to
rotate at the same speed.
4WD Low Indicator Light — If Equipped
This light alerts the driver that the
vehicle is in the four-wheel drive LOW
mode. The front and rear driveshafts
are mechanically locked together
forcing the front and rear wheels to rotate at the
same speed. Low range provides a greater gear
reduction ratio to provide increased torque at
the wheels Ú page 154.
4WD Part Time Indicator Light — If
Equipped
This light alerts the driver that the
vehicle is in the four-wheel drive part
time mode, and the front and rear
driveshafts are mechanically locked
together forcing the front and rear wheels to
rotate at the same speed.
Axle Locker Fault Indicator Light
This light indicates when the front
and/or rear axle locker fault has been
detected.
Forward Collision Warning (FCW) OFF
Indicator Light — If Equipped
This indicator light illuminates to
indicate that Forward Collision
Warning is off Ú page 297.
Front And Rear Axle Lock Indicator Light
This light indicates when the front,
rear, or both axles have been locked.
The telltale will display the lock icon
on the front and rear axles to indicate
the current lock status.
Neutral Indicator Light — If Equipped
This light alerts the driver that the
vehicle is in the neutral mode.
Rear Axle Lock Indicator Light
This light indicates when the rear axle
lock has been activated Ú page 154.
Service Adaptive Cruise Control Warning
Light — If Equipped
This light will turn on when a ACC is
not operating and needs service
Ú page 170.
Sway Bar Indicator Light — If Equipped
This indicator light will illuminate
when the front sway bar is
disconnected.
Wait To Start Light — If Equipped
This indicator light will illuminate for
approximately two seconds when the
ignition is turned to the ON/RUN
position. Its duration may be longer
based on colder operating conditions. Vehicle
will not initiate start until telltale is no longer
displayed Ú page 134.
NOTE:
The “Wait To Start” telltale may not illuminate if
the intake manifold temperature is warm
enough.
3
