IN CASE OF EMERGENCY 349
(Continued)
2. Remove the hardware storage cover by
pinching the latch on the left side and
pulling upward.
Hardware Storage Cover Latch
3. Turn the plastic wing nut counterclockwise
to loosen the jack from the storage bin.
Plastic Wing Nut Location
4. Remove tool kit and assemble tools.
SPARE TIRE REMOVAL
1. To remove the spare tire from the carrier,
remove the tire cover, if equipped.
2. Remove the Rear Camera Cover by turning
the lock bolt counterclockwise with the
#T40 torx head driver and ratchet from the
supplied tool kit.
Unlock Rear Camera Cover
3. Remove the lug nuts with the lug wrench
turning them counterclockwise. If equipped,
remove the locking lug nut with the lock key
(located in the glove box) turning it counter-
clockwise.
Removing The Spare Tire
JACKING INSTRUCTIONS
WARNING!
Carefully follow these tire changing warnings
to help prevent personal injury or damage to
your vehicle:
Always park on a firm, level surface as far
from the edge of the roadway as possible
before raising the vehicle.
Turn on the Hazard Warning Flashers.
Apply the parking brake firmly and shift an
automatic transmission in PARK; a manual
transmission to REVERSE.
7
