398 SERVICING AND MAINTENANCE
F87 – 10 Amp Red SUPPLY/PURGING PMP — If Equipped
F88 20 Amp Blue – NOx SENSOR #1/ #2 — IF Equipped
F89 – 10 Amp Red
Steering Column Control Module (SCCM)/ Cruise Control
(CRUISE CTL)/Digital TV (DTV)
F90 20 Amp Blue – TRAILER TOW PARK LMP — If Equipped
F91 – 20 Amp Yellow HORN
F92 40 Amp Green – HD ACCY #2 — If Equipped
F93 40 Amp Green – HD ACCY #1 — If Equipped
F94 – 10 Amp Red Tire Pressure Monitor (TPM)/RF Hub system (CORAX)
F95 – – Spare
F96 – 10 Amp Red PWR MIRROR SW
F97 – 20 Amp Yellow RADIO/TBM
F98 – 10 Amp Red SW BANK-HD ELEC/OFF ROAD
F99 – – Spare
F100 30 Amp Pink – ESC-ECU & VALVES
F101 30 Amp Pink – DriveTrain Control Module (DTCM)
F102 – 15 Amp Blue DUAL USB PORT
F103 – 15 Amp Blue HD ACCY #3 — If Equipped
F104 – 15 Amp Blue PPU COOL PUMP — If Equipped
F105 – 10 Amp Red
Integrated Center Stack (ICS)/Heat Ventilation Air Condi-
tioning (HVAC)
Cavity Cartridge Fuse Micro Fuse Description
