SERVICING AND MAINTENANCE 401
Bulb Replacement
NOTE:
Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as
atmospheric conditions change to allow the
condensation to change back into a vapor.
Turning the lamps on will usually accelerate the
clearing process.
Halogen Headlamps
See below steps to replace:
1. Open hood and support using prop rod.
2. Remove the front grille. Turn the retainers
along the top a quarter turn counter-
clockwise and remove.
3. Pull the bottom of the grille away starting at
one side and working toward the other.
4. Remove the three screws holding the
headlamp to the vehicle.
5. Remove lamp from the vehicle.
6. Remove the lamp from the collar.
7. Grab the bulb and rotate a quarter turn
counterclockwise.
8. Pull the bulb from the housing.
Front Side Marker Lamps (2) LED – (Serviced at an authorized dealer)
Base Fog Lamps PSX24W
Premium Fog Lamps LED – (Serviced at an authorized dealer)
Rear Premium LED Tail Lamps LED – (Serviced at an authorized dealer)
Rear Base Tail Lamp Stop/Tail/Turn Bulb 3157
Rear Base Tail Lamp Backup Bulb 7440
Rear Base Tail Lamp Side Marker LED – (Serviced at an authorized dealer)
Center High Mounted Stop Lamp (CHMSL) LED – (Serviced at an authorized dealer)
License Lamp LED – (Serviced at an authorized dealer)
NOTE:
Numbers refer to commercial bulb types that can be purchased from an authorized dealer. If a bulb needs to be replaced, visit an authorized dealer
or refer to the applicable Service Manual.
Exterior Bulbs
Bulb Name Bulb Number
