GETTING TO KNOW YOUR VEHICLE 81
6. From inside the vehicle, pull the handle on
the header latch downward to engage the
hook into its receiver. Repeat on the other
side.
Step Six
7. Pull the handle back upward while squeezing
the hook, locking the latch into place.
Step Seven
Installing The Soft Top Windows
Install The Right And Left Quarter Windows
1. From the rear of the vehicle, guide the top
of the window into the retainer and slide
forward while keeping the window level.
Repeat on the other side.
Step One
2. Place the top of the quarter window pillar
into the top cover, and insert the bottom tab
into the clip.
Step Two
Step Two
CAUTION!
Failure to follow all Quarter Window Install
steps could result in damage to the Soft Top
or vehicle.
2
21_JL_OM_EN_USC_t.book Page 81
