Installation Cont.
7
Step 7
Load cargo carrier paying careful attention to
distribute the weight evenly and not exceed
the maximum allowed weight of the box or cross rails.
Close the carrier. Be sure that both side alignment
brackets are not visible. Close the bale latches on
each side, and insert clip hooks to secure.
Both side alignment brackets must not be visible.
Slide Alignment
Bracket
Step 7
Be sure cargo carrier is fully closed. When this
occurs, the yellow warning label will no longer
be visible.
Place key in lock and turn to vertical position. Then
remove key to prevent lock from allowing box to
open. Remove and store key.
Correct
Incorrect
Unlocked Locked
To Next Page
