JTM-69A V2.0 10/07
14
Fuse Replacement
WARNING: To avoid electric shock, disconnect the test leads from
any source of voltage before removing battery/fuse cover.
1. Disconnect the test leads from any circuit being measured.
2. Remove the rubber holster (if in place).
3. Open the battery/fuse cover by removing the screws on the rear
using a Phillips screwdriver.
4. Remove the battery cover.
5. Remove the old fuse by gently pulling up on it.
6. Install the new fuse by gently pushing it into the holder.
7. Always use a fuse of the proper size and value (0.5A/250V fast
blow or 10A/250V fast blow).
8. Replace the cover and secure with the screws.
