Jensen JTM-69A - Specifications

JTM-69A V2.0 10/07
4
Specifications
Function Range Resolution Accuracy
400mV 0.1mV
±(0.5% reading + 2 digits)
4V 0.001V
40V 0.01V
400V 0.1V
±(1.0% reading + 2 digits)
DC Voltage
600V 1V
±(1.5% reading + 2 digits)
400mV 0.1mV
±(1.0% reading + 70 digits)
4V 0.001V
±(1.0% reading + 3 digits)
40V 0.01V
400V 0.1V
±(1.2% reading + 3 digits)
AC Voltage
50/60Hz
600V 1V
±(2.0% reading + 4 digits)
400μA 0.1μA
4000μA 1μA
40mA 0.01mA
400mA 0.1mA
±(1.5% reading + 3 digits)
DC Current
10A 0.01A
±(2.5% reading + 5 digits)
400μA 0.1μA
4000μA 1μA
40mA 0.01mA
400mA 0.1mA
±(1.8% reading + 5 digits)
AC Current
50/60Hz
10A 0.01A
±(3.0% reading + 7 digits)
400Ω 0.1Ω ±(1.0% reading + 4 digits)
4kΩ 0.001kΩ ±(1.0% reading + 2 digits)
40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MΩ
±(1.2% reading + 2 digits)
Resistance
40MΩ 0.01MΩ ±(2.0% reading + 5 digits)
