JTM-69A V2.0 10/07
5
4nF 0.001nF
±(5.0% reading + 10digits)
40nF 0.01nF
±(5.0% reading + 7 digits)
400nF 0.1nF
±(3.0% reading + 5 digits)
4μF 0.001μF
40μF 0.01μF
±(3.5% reading + 5 digits)
Capacitance
200μF 0.1μF ±(5.0% reading + 5 digits)
9.999Hz 0.001Hz
99.99Hz 0.01Hz
±(1.5% reading + 5 digits)
999.9Hz 0.1Hz
9.999kHz 0.001kHz
99.99kHz 0.01kHz
999.9kHz 0.1kHz
±(1.2% reading + 2 digits)
9.999MHz 0.001MHz
±(1.5% reading + 4 digits)
Frequency
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle
and <100kHz; 5Vrms min @ 20% to 80% duty cycle
and > 100kHz.
Function Range Resolution Accuracy
Duty Cycle 0.1 to 99.9% 0.1%
±(1.2% reading + 2 digits)
Pulse width: 100μs - 100ms
Frequency: 5Hz to 150kHz
Temp °F -4 to 1400°F 1°F
Temp °C -20 to 760°C1°C
±(3.0% reading + 3 digits)
(meter only, probe accuracy
not included)
NOTE: Accuracy is stated at 65
o
F to 83
o
F (18
o
C to 28
o
C) and less than
70% RH.
