Jet DC-3500 User Manual

10
CONTENTS OF PACKAGE:
TRANSPORTATION:
Packing handling must be carried out exclusively
using a forklift truck.
Position the forks keeping the package properly
balanced.
Place the package on the floor.
Remove package enveloping the machine.
NO.
Description
QTY
NO.
Description
QTY
A
Collector Body & Fan /
Motor Assembly
1
G
Nuts, Screws, Washer,
Spring Washers, and Wrench
B
Collector Body
2
H
Hanger
2
C
Inlet
1
I
Gasket
1
D
Main Base
1
J
Casters
4
E
Right and Left Side Legs
4
K
Upper Filter Bag
2
F
Bag Support
2
L
Bottom Plastic Bag
2
