4.0 Specifications
Model number ......................................................................................................................................... JCDC-1.5
Stock number .............................................................................................................................................. 717515
Motor and electricals:
Motor type ........................................................................ .totally enclosed fan cooled, induction, capacitor start
Horsepower ............................................................................................................................. 1-1/2 HP (1.1kW)
Phase .......................................................................................................................................................... single
Voltage ................................................................................................................................................. 115V only
Cycle ............................................................................................................................................................ 60Hz
Listed FLA (full load amps) ........................................................................................................................... 14 A
Starting amps ................................................................................................................................................ 52 A
Running amps (no load) ............................................................................................................................... 13 A
Start capacitor .......................................................................................................................... 300MFD 125VAC
Run capacitor ..................................................................................................................................... 30μF 250V
On/off switch ........................................................................................................... toggle switch with safety key
Motor speed ........................................................................................................................................ 3450 RPM
Power cord ........................................................................................................................ 14AWG x 3C, 6ft.,SJT
Power plug ................................................................................................................. 5-15P, 125V/15A installed
Recommended circuit and fuse/breaker size
1
.............................................................................................. 20A
Sound emission
2
............................................................................................................... 75 dB at 9.84 ft. (3m)
Remote control system ............................................ radio frequency (FCC approved); range up to 50 ft. (15 m)
RC transmitter battery ...................................................................................................................................... 9V
Performance:
Inlet diameter ................................................................................................................................ 6 in. (152 mm)
Inlet adaptors, number of ................................................................................................................................... 2
Inlet adaptors, diameter of ............................................................................................................. 4in. (100 mm)
Filter efficiency .................................................................. 99% of 2 micron particles; 86% of 1 micron particles
US method EU method
Air Flow with filters installed .............................. 763 CFM (1293 m
3
/hr) ........................ 1259 CFM (2134 m
3
/hr)
Air Velocity .......................................................... 3877 FPM (18.5 m/s) .......................... 6396 FPM (32.50 m/s)
Static pressure loss (WC) ............................ 1.535 inH
2
O (39 mmH
2
O) ......................2.677 inH
2
O (68 mmH
2
O)
Maximum static pressure loss (WC) .......... 8.268 inH
2
O (210 mmH
2
O) ....................8.268 inH
2
O (210 mmH
2
O)
Impeller:
Impeller diameter ........................................................................................................................ 13 in. (330 mm)
Impeller type .......................................................................................................................................... radial fin
Impeller material .......................................................................................................................................... steel
Canister filter:
Filter type ........................................................................................................ cartridge and spunbond polyester
Canister filter diameter ........................................................................................................ 14-9/16 in. (370 mm)
Canister filter length .............................................................................................................. 15-3/4 in. (400 mm)
Filter surface area .................................................................................................................... 21.53 sq. ft. (2m
2
)
Filter efficiency ............................................................................................................. 99% of 2 micron particles
Cleaning system ............................................................................................................ manual scraper rotation
Collection drum:
Capacity .................................................................................................................................................... 20 gal.
Diameter ............................................................................................................................. 16-9/16 in. (420 mm)
Height ............................................................................................................................... 19-11/16 in. (500 mm)
Material ........................................................................................................................................................ steel
1
Subject to local/national electrical codes. Recommendation based upon dedicated circuit.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
