Jet JCDC-3 User Manual

5
4.0 Specifications
Model number ............................................................................................................................................ JCDC-3
Stock numbers:
Complete kit ....................................................................................................................................... 717530K
Main unit only ....................................................................................................................................... 717530
Canister filter only ............................................................................................................................... 717530F
Motor and electricals:
Motor type ........................................................................ .totally enclosed fan cooled, induction, capacitor start
Horsepower ................................................................................................................................... 3 HP (2.2kW)
Phase .......................................................................................................................................................... single
Voltage ................................................................................................................................................. 230V only
Cycle ............................................................................................................................................................ 60Hz
Listed FLA (full load amps) ........................................................................................................................... 13 A
Starting amps ................................................................................................................................................ 39 A
Running amps (no load) ............................................................................................................................ 12.5 A
Start capacitor ......................................................................................................................... 500MFD, 125VAC
Run capacitor ..................................................................................................................................... 40μF 300V
On/off switch .............................................................. push-button, magnetic contactor with overload protection
Motor speed ........................................................................................................................................ 3450 RPM
Power cord ........................................................................................................................ 12AW G x 3C, 6ft.,SJT
Power plug ................................................................................................................. 6-20P, 250V/20A installed
Recommended circuit and fuse/breaker size
1
............................................................................................. 20 A
Sound emission (at 9.84 ft./3m)
2
................................................................................................................ 76 dB
Remote control system ............................................ radio frequency (FCC approved); range up to 50 ft. (15 m)
RC transmitter battery ...................................................................................................................... 2 x AA, 1.5V
Timer setting ................................................................................................................................ 2, 4, 6, 8 hours
Performance:
Inlet diameter ................................................................................................................................ 8 in. (203 mm)
Inlet adaptors, number of ................................................................................................................................... 3
Inlet adaptors, diameter of ............................................................................................................. 4in. (100 mm)
Filter efficiency ............................................................................................................. 99% of 2 micron particles
US method EU method
Air Flow with filters installed ............................ 1240 CFM (2102 m
3
/hr) ........................ 1963 CFM (3327 m
3
/hr)
Air Velocity ............................................................. 3542 FPM (18 m/s) ............................ 5609 FPM (28.5 m/s)
Static pressure loss (WC) ............................ 1.260 inH
2
O (32 mmH
2
O) ......................2.047 inH
2
O (52 mmH
2
O)
Maximum static pressure loss (WC) .......... 8.976 inH
2
O (228 mmH
2
O) ....................8.976 inH
2
O (228 mmH
2
O)
Impeller:
Impeller diameter ........................................................................................................................ 15 in. (380 mm)
Impeller type .......................................................................................................................................... radial fin
Impeller material .......................................................................................................................................... steel
Canister filter:
Filter type ........................................................................................................ cartridge and spunbond polyester
Canister filter diameter ........................................................................................................ 14-9/16 in. (370 mm)
Canister filter length .............................................................................................................. 38-3/8 in. (975 mm)
Filter surface area ................................................................................................................ 45.21 sq. ft. (4.2 m
2
)
Filter efficiency ............................................................................................................. 99% of 2 micron particles
Cleaning system ............................................................................................................ manual scraper rotation
Collection drum:
Capacity .................................................................................................................................................... 66 gal.
Diameter ............................................................................................................................. 24-7/16 in. (620 mm)
Height ................................................................................................................................... 31-7/8 in. (810 mm)
Material ........................................................................................................................................................ steel
1
Subject to local/national electrical codes. Recommendation based upon dedicated circuit.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
