Jet Force Junior 5
Pre air filter
HEPA filter
Soft rubber ring
Hard plastic ring
Replace HEPA Filter and Clean Pre-filter
Replace water tray and uninstall hand dryer from wall
Water Tray
Water overflow pipe
to floor drain
Power ON/OFF
Air Hot/Cold
Speed High/Low
WARNING: Disconnect power at the service breaker or unplug the hand dryer before servicing & maintenance.
1. Press back then down to remove the pre-filter.
2. Take the HEPA filter out. When replacing the HEPA filter, ensure the soft rubber edge is uppermost.
3. Clean any dust from the pre-filter.
2 x anti-tamper screws
1. If there is a water overflow pipe connected, remove it.
2. Remove the tray by pulling it forward. Then undo the2 x anti-tamper screws.
3. First pull up then pull front to take hand dryer from wall. Do this carefully as the dryer weighs 11KG.
5. On reinstallation, before replacing the water tray, make sure the heater and speed switches are set as required.
