Jetmaster UNIVERSAL 440 Installation Instructions

0
25
45
50
90
100
150
170
200
250
300
350
100
200
300
400
500
230
320
380
425
460
483
X
Y
Mantel / Surround projection from wall
Top Clearance (mm)
Height from top of firebox to underside of mantel/surround
Fig. 21
If you are using a decorative surround constructed of combustible material, it must be located within the shaded area
defined in Fig. 21
Projection (mm)
Combustible
Materials
Non-Combustible
Materials
X
Y
1
23
4
5
6
Notes:
1. Mantel / Surround
2. Tile or margin facing (non combustible material)
3. Hebel Block
4. Firebox
5. Gather
6. Flue
X See Fig. 21
Y See Fig. 21
Fig. 20
Drawing Not To Scale
CLEARANCE TO COMBUSTIBLE MANTELS
5.TW.1J
Drawing Not To Scale
