LOCKING RING
LOCKING RING TAB
3. SECURE THE LATCH WITH THE LOCKING RING:
ROTATE THE RING CLOCKWISE AROUND THE
STEM UNTIL THE TAB ON THE RING SLIDES
INTO THE TAB SLOT ON THE LATCH.
4. CHECK THAT THE LATCH IS SECURED BY
ENSURING THAT IT CANNOT BE PULLED OPEN.
IMPORTANT: NEVER RIDE THE ATLAS WITHOUT THE FOLDING
LATCH CLOSED AND SECURED BY THE LOCKING RING.
