2. CAREFULLY TUCK THE WIRES INTO THE HOLE IN THE STEM
FACING THE RIDER'S SIDE WHILE YOU LOWER THE LOWER THE
HANDLEBAR ONTO THE CLAMP BOTTOM.
3. POSITION THE HANDLEBAR ON THE CLAMP BOTTOM SUCH THAT
THE FOLLOWING CONDITIONS ARE MET:
· THE LCD SCREEN IS ON THE RIGHT SIDE AS VIEWED FROM THE
RIDING POSITION.
· THE HANDLEBAR IS CENTERED ON THE CLAMP BOTTOM.
· THE HANDLEBAR IS ROTATED IN THE STEM SUCH THAT THE
HOLE THROUGH THE HANDLEBAR IS ALIGNED WITH THE HOLE
IN THE CLAMP BOTTOM.
· THE WIRES ARE TUCKED ALL THE WAY INTO STEM.
WIRES
CLAMP BOTTOM
HANDLEBAR
WIRE ENTRY POINT
(OPPOSITE SIDE; NOT SHOWN)
STEM
*AS VIEWED FROM IN FRONT
OF THE SCOOTER.
