BOLT
4. PLACE THE CLAMP TOP OVER THE CENTER OF THE
HANDLEBAR SUCH THAT THE HOLE IN THE TOP IS ALIGNED
WITH THE HOLES IN THE HANDLEBAR AND CLAMP BOTTOM.
5. INSERT THE BOLT THROUGH THE ALIGNED HOLES BY
TWISTING IT IN CLOCKWISE.
6. TIGHTEN THE BOLT BY TWISTING IT CLOCKWISE WITH THE
5MM ALLEN KEY.
7. CHECK THAT THE HANDLEBAR IS SECURE IN THE CLAMP.
5MM ALLEN KEY
CLAMP TOP
CLAMP BOTTOM
HANDLEBAR
*AS VIEWED FROM IN FRONT
OF THE SCOOTER.
