Solar Controller-SCM48100 User Manual
○11. Secondary Load: 3 channels of DC output secondary load;
○12. Battery1和Battery2: Cathode interface of storage battery;
2.4 Outer Structure of Cabinet and Installation Instructions
System Installation Method:
SCM48100 is an embedded solar controller system. During installation, the plug-in frame of
solar controller is horizontally jacked up and inserted in a designated position. Make sure the
plug-in frame is properly installed. 4 mounting holes of suspension loop correspond to the
installation holes of cabinet. Four M6 cross recess round head combination screw (fitted with
