Solar Controller-SCM48100 User Manual
5
Indexes and specifications are subject to change without notice.
Technical characteristics and
parameters
Description
SCM48100
Remark
Default rated output voltage
(V)
54.0
/
Rated output current (A)
100
/
Maximum photovoltaic input
power (kW)
5.7
/
Maximum current of
photovoltaic array (A)
44
Single channel of PV input
Maximum photovoltaic input
voltage (V)
260
The module starts when the input is not lower
than 70Vdc.
Range of MPPT working
voltage (V)
70~250
Number of single channel PV input groups:
Three serial connections and three parallel
connections
Range of output voltage
(settable V)
42.0~58.0
Adjusted through monitoring module
Input overvoltage protection
point (V)
260±5
Input overvoltage protection of MPPT module
Input overvoltage protection
recovery point (V)
250±5
Self-recoverable
Output overcurrent protection
range (A)
101~110
/
Output overvoltage protection
range (V)
58.5~60
Input overvoltage protection of MPPT module
(default: 59Vdc)
MPPT module efficiency
>95%
150Vdc input; load test above 50^
Utilization rate of photovoltaic
module
>99%
The output power is tested within load range
with rated power of 5% and above, including
when the input power is quickly changed.
Service ambient temperature
(℃)
-20~+55
/
Service altitude (m)
≤3000
When the altitude exceeds 3,000m, the output
power is de-rated by 10% for each 50mm
ascended.
