3.3. Product performance
04/Product Installation
Configuration
Operating voltage
Operating
temperature
Storage
temperature
ESD protection
DC9-33V
–20˚C to 70˚C
–30˚C to 85˚C
Air ±8KV;
contact ±4KV
Undervoltage
protection
Overvoltage
protection
Reverse connection
protection
Flame retardant
9V
36V
Support
UL94 V-0
Parameter Performance Parameter
●
●
●
●
●
●
4.1 Notices
This device is for use with gasoline-powered vehicles only. Please do not use it with
all-electric or hybrid vehicles;
Use the supplied accessories for the installation;
The power supply for the device is DC9-33V. Please connect the positive and negative
terminals of the power cable correctly to prevent any damage to the vehicle;
When installation is complete, remove the protective film from the camera lens for
optimal capture effect;
Use a memory card and a SIM card recommended in this guide;
Ask your dealer or a professional agency to perform the installation and testing as
described in this guide.
3.2. Configuration and parameters
Configuration
Communication
network
Speaker
Front camera (main)
GNSS
WiFi
4G Cat.1
Support
1920 × 1080
GPS & BDS
2.4G 802.11 b/g/n AP
mode (no WiFi hotspot)
CPU
Microphone
Sub camera
G-sensor
Memory card
ARM Cortex A7
Support
640 × 360
3-axis
Micro SD card in FAT32
16GB–128GB
Parameter Configuration Parameter
Frequency bands
(vary with the model
you purchase)
JC181-LA
4G FDD: B1/B2/B3/B4/B5/B7/B8/B28
2G GSM: B2/B3/B5/B8
JC181-EU
4G FDD: B1/B3/B5/B7/B8/B20/B28
4G TDD: B38/B40/B41
2G GSM: B2/B3/B5/B8
5
