JL Audio e110 - Rear Connection Panel Layout

CH. 2
(
R
)
Grounded
Isolated
CH. 1
(
L
)
HIGH LEVEL INPUTS
SERIAL NUMBER:
Warranty void if serial number is
removed, altered or defaced.
LINE
OUTPUTS
LL
RR
LINE
INPUTS
Built in USA
with domestic and
imported components
Page 13 | e110 & e112
Rear Connection Panel (120V Model Shown)
 e labeled Figure below depicts the rear panel of the E-Sub subwoofer.
 e e110 and e112 have identical layouts.
Line
Inputs
page 17
Grounded/
Isolated
Switch
page 17
IEC-Style AC
Connector
page 18
Line
Outputs
page 18
High Level
Inputs
page 17
