16 | JL Audio - 1000/1v2 Owner’s Manual
17
APPENDIX C:
Precise Frequency Selection Chart
CHART A1
AMPLIFIER LOWPASS FILTER
Detent Panel Actual
Number Marking Freq.
Full counter-clockwise: 42
01 ............................42
02 ............................42
03 ............................42
04 ........... “40” ............42
05 ............................43
06 ............................44
07 ............................46
08 ........... “45” ............47
09 ............................49
10 ............................50
11 ............................52
12 ............................53
13 ............................55
14 ........... “55” ............57
15 ............................58
16 ............................60
17 ............................63
18 ............................65
19 ........... “65” ............67
20 ............................70
21 ............................73
22 ............................76
23 ............................79
24 ........... “80” ............83
25 ............................87
26 ............................92
27 ............................96
28 ...........................102
29 ...........“100”...........108
30 ...........................114
31 ...........................122
32 ...........................131
33 ...........................143
34 ...........................157
35 ...........................184
36 ...........“200”...........193
37 ...........................198
38 ...........................198
39 ...........................198
Full-clockwise : 198
CHART A2
PREAMP OUTPUT SECTION
Detent Panel Actual
Number Marking Freq.
Full counter-clockwise: 41
01 ............................41
02 ............................41
03 ............................41
04 ........... “40” ............42
05 ............................42
06 ............................43
07 ............................44
08 ........... “45” ............45
09 ............................47
10 ............................48
11 ............................49
12 ............................51
13 ............................53
14 ........... “55” ............54
15 ............................56
16 ............................58
17 ............................60
18 ............................62
19 ........... “65” ............64
20 ............................67
21 ............................69
22 ............................72
23 ............................75
24 ........... “80” ............78
25 ............................82
26 ............................86
27 ............................90
28 ............................95
29 ...........“100”...........100
30 ...........................107
31 ...........................113
32 ...........................122
33 ...........................131
34 ...........................143
35 ...........................156
36 ...........“200”...........169
37 ...........................186
38 ...........................192
39 ...........................197
Full-clockwise : 197
CHART A3
INFRASONIC FILTER
Detent Panel Actual
Number Marking Freq.
Full counter-clockwise: 14
01 ............................14
02 ............................14
03 ............................14
04 ........... “15” ............14
05 ............................15
06 ............................15
07 ............................16
08 ........... “18” ............17
09 ............................17
10 ............................18
11 ............................19
12 ............................20
13 ............................20
14 ........... “25” ............21
15 ............................22
16 ............................24
17 ............................25
18 ............................27
19 ............................28
20 ........... “30” ............30
21 ............................33
22 ............................35
23 ............................39
24 ............................42
25 ........... “40” ............47
26 ............................50
27 ............................51
28 ............................54
29 ............................56
30 ............................56
31 ........... “50” ............57
32 ............................58
33 ............................58
34 ............................58
35 ............................59
36 ........... “60” ............60
37 ............................61
38 ............................61
39 ............................61
Full-clockwise : 61
CHART A4
EQ CENTER FREQUENCY
Detent Panel Actual
Number Marking Freq.
Full counter-clockwise: 22
01 ............................22
02 ............................22
03 ............................22
04 ........... “20” ............22
05 ............................22
06 ............................24
07 ............................24
08 ........... “25” ............25
09 ............................26
10 ............................27
11 ............................28
12 ............................30
13 ............................31
14 ........... “30” ............32
15 ............................34
16 ............................35
17 ............................38
18 ............................40
19 ........... “40” ............42
20 ............................45
21 ............................48
22 ............................51
23 ............................56
24 ........... “60” ............61
25 ............................67
26 ............................69
27 ............................72
28 ............................75
29 ........... “75” ............76
30 ............................77
31 ............................77
32 ............................78
33 ............................79
34 ............................80
35 ............................81
36 ........... “80” ............81
37 ............................81
38 ............................81
39 ............................81
Full-clockwise : 81
