SECTION 4 - MACHINE OPERATION
4-6 – JLG Lift – 3120854
Lifting
If it becomes necessary to lift the machine, it is possible to
lift the machine with a forklift. On 2032E2/2632E2/2646E2
and 3246E2 forklift pockets are provided at the front and
rear of the machine. The 1932E2 can only be lifted from
the rear forklift pockets. It is very important that the forklift
operator use only the designated lifting areas to lift the
machine.
NOTE: Do not lift the machine from the sides.
Forklifts, cranes, or other lifting devices must be capable
of handling the following weights:
TOWING
It is not recommended that this machine be towed, except
in the event of an emergency such as a machine malfunc-
tion or a total machine power failure. Refer to Section 6 for
emergency towing procedures.
Model
GVW CE Specifications
(Approximate)
1932E2 1360 kg
2032E2 2091 kg
2632E2
(Australian Only)
2415 kg
2646E2 2086 kg
3246E2 2804 kg
XZ
MODEL
FRONT REAR LEFT RIGHT
1932E2 603 617
1360
117 79 39
2032E2
2646E2
982
932
837
982
2091
2086
174
174
90
86 52
34
FRONT AXLE
(kg.)
REAR AXLE
(kg.)
GVW
kg)
WHEELBASE
(cm)
X
(cm.)
Z
(cm.)
3246E2
2804
174
1506 1298
93
52
2632E2
2415
1254 1161
174
90
34
Figure 4-3. Lifting Chart
