JLL R200 Owner's Manual

- 4 -
PARTS LIST
NO.
Description
QTY
NO.
Description
QTY
1
Main frame
1
40
Steel bushing
2
2
Knob M10×25
2
41
Bearing
8
3
End cap
2
42
PU wheel
4
4
Foam grip
2
43
Sleeve 1
2
5
Handlebar
1
44
Plate
1
6
Computer
1
45
Screw M6×20
2
7
Tension control
1
46
Connection wire
1
8
Flat washer D10×2.0×φ20
4
47
Slide plate
2
9
Nylon nut M10
2
48
Rotary plate
1
10
Flat washer D13×2.0×φ26
2
49
Bearing 6000
2
11
Pedal
2
50
Plug
2
12
Bolt M12×155×16
2
51
Bushing
2
13
Saddle
1
52
Flywheel
1
14
Hexagon bolt M10×100
1
53
Nut M6
2
15
Knob M16×1.5
1
54
Screw ST4.2X18
4
16
Nylon nut M8
3
55
Hexagon bolt M6×15
2
17
Flat washer D8×1.5×φ16
5
56
Arc washer D6
2
18
Slide rest
1
57
Flat washer D6×1.0×φ12
2
19
Hexagon bolt M8×110
3
58
Pulley
1
20
Sleeve 2
1
59
Screw ST4.2X18
7
21
Wheel
2
60L/R
Chain cover
1 each
22
Slide way
1
61
Bolt M10×1.0
2
23
Tension belt
1
62
Hexagon bolt M10×1.0
6
24
Cushion
4
63
Handlebar shaft
1
25
Hexagon bolt M10×95
1
64
Spring
1
26
Screw M6×15
4
65
Axle
1
27
Screw ST4.2×8
4
66
Washers D12
2
28
Protect guard
1
67
Cushion
2
29
Stand rail
1
68
Screw ST3.5×18
3
30
Carriage bolt M8×73
2
69
End cap
1
31
Arc washer
D8×2×Φ25×R30.5
2
70
Plastic cap S17
2
32
Cap nut M8
2
71
Rubber pad
1
33
Front bottom tube
1
72
Over lay
1
34
End cap
2
73
Washers D10
2
35
Flat washer
1
74
Sleeve3
1
36
Sensor
1
75
Hexagon bolt M8×10
2
37
Screw ST3X10
2
76
Bearing 6001
2
38
Rubber pad
1
77
Belt
1
39
Magnet
1
