JM POSNER SQ2 - Fountain Assembly SQ2 Cascade; SQ2 Cascade Assembly Steps

6
STEP 1
Removefountaincomponentsfromtheirboxes
andplacefountaindrumonasturdy,level
surface.Makesurethedrumislevelsothatthe
chocolatewillowproperly.
STEP 2
Placethebasinontopofthedrumatan
angleandpushdownandturnclockwise45
degreestolockthebasinwithdrum.Tocheck
thefountainislevelplaceaspiritlevelonthe
basinrimatvariouslocations(Fig.1).Ifleveling
isneeded,raiseorloweraparticularsideofthe
fountainbyadjustingthefeet.
STEP 3
Placeaugerontopofthesquarecentreshaftin
themiddleofbasin(Fig.2).
STEP 4
Placethecentrecolumnontothecentre
housinginthemiddleofthefountainbase(Fig.
3).Ensurethattheslotonthecolumnbaselines
upwiththelocatingpinontheinsideofthe
housing.Pleasenotethattheaugerwillnotll
thewholelengthofthecolumn,thisisnormal
anddoesnotaffectoperationofthefountain.
STEP 5
PlacetheCupsonthecentrecolumn,
matchingthenumbersonthecupswiththe
correctnumberedbracketonthecolumn(Fig.
4).Forexample,cupA1mustattachtobracket
A1;thereare10cupsintotal,A1-A5andB1-B5.
STEP 6
Placethetophatontopofthecentrecolumn.
STEP 7
Placethedecorativeballintothetophat.
FOUNTAIN ASSEMBLY SQ2 CASCADE
Centre & Locating Pins
Slot in column
Fig. 1
Fig. 2
Fig. 3
Fig. 4
