NT-2000 REF Manual
Customizing Operation via Menu System
4-14
4.10.4. Outputting NAVTEX Messages of Specific Receiver
If you wish to output all NAVTEX messages received from either receiver (first or
second receiver) alone, carry out the following step–by–step procedure:
NOTE: A forced carriage return
(
)
will be replaced by an underscore
( _ ) (
hex 5F
)
when it
is output to a PC terminal or a printer
.
(1) Highlight option “3:MSG SELECTED BY FREQUENCY” on the SELECT
OUTPUT MESSAGES submenu, and then press
. This turns on another
submenu with the following options, enabling you to select the desired receiver, as
in the example illustrated below:
1: FIRST RECEIVER
(
518 KHZ
): Outputs first receiver messages.
2: SECOND RECEIVER: Outputs second receiver messages.
Figure 4-21 Outputting Stored Messages of First Receiver – Example
(2) Highlight the desired option, and then press
. The following window will pop
up to indicate the outputting action in progress.
The window will be turned off automatically upon completion of outputting.
To cancel the action, press
.
(3) Press
to return to the previous menu or
to return to the first receiver
message screen.
OUTPUTTING ALL STORED MESSAGES.
TO CANCEL, PRESS
[
CLR
]
.
To derive first receiver messages from
memory, select this option with
, and then press
.
6: SELECT OUTPUT MESSAGES
1: RECEIVING MSG ON IOFFI
2: ALL STORED MSG
3: MSG SELECTED BY FREQUENCYi
4: MSG SELECTED BY STATION
5: MSG SELECTED BY TYPE
6: DISPLAYED MSG – ALL
7: DISPLAYED MSG – SPECIFIC
3: MSG SELECTED BY FREQUENCY
1: FIRST RECEIVER
(
518 KHZ
)
2: SECOND RECEIVER
