NT-2000 REF Manual
Installation
7-5
7.3. Electrical Connections
7.3.1. Introduction
All electrical connections to the equipment are to be made via the connector receptacles
and terminal installed on the rear panel and the rear apron. The figure below shows the
rear view of the equipment. Overall connections are illustrated in Figure 7–5. A
summary description of the necessary connections to each component is given in the
next paragraphs.
< CAUTIONS >
1. All cables should be plugged in with the equipment switched off.
2. Cables specified for use with the F–2000/F–3000 or DEBEG 4620/DEBEG 4630
Navigation Sounders cannot be used as alternative cables.
Figure 7-4 Rear View
(
continued on next page
)
⑦ ⑤ ⑥ ④ ⑩
⑧ ③ ① ② ⑨
Rear Panel
Rear Apron
To Next Page
