JN-MPPT Buck series solar charge controller
address:no.99 yonghe road.Hefei.Anhui.China Tel0551-65372576 http://www.hfjnge.com
- 4 -
The controller running parameters can be viewed and set through the PC host
computer and mobile phone APP. For details, refer to the host computer and
APP manual (optional).
With battery temperature compensation.
It has comprehensive protection functions such as overcharge, over discharge,
over temperature, overload, reverse connection and so on.
3. product appearance
3.1 product appearance
pic 2-1: Product appearance dimension drawing
Table 2-1
Product weight and size
parameter name
Weight and Size
Model no.
JN-MPPT-MINI
JN-MPPT-AL
JN-MPPT-BL
JN-MPPT-CL
weight(kg)
1.25Kg
1.5kg
2.3kg
3.6kg
Size L*D*H(mm)
156*134*81mm
186*146*81mm
240*170*97mm
340*208*95mm
