The JOCCA HOME & LIFE Ref: 2145 is a kitchen robot designed to assist with various cooking and food preparation tasks. It features a robust design with a black base and a stainless steel measuring jug, topped with a transparent lid and a dosing cap. The device is equipped with a digital control screen for easy operation and offers both manual and automatic programs, as well as Wi-Fi connectivity for smart control via the "Tuya Smart" application.

Function Description:

The kitchen robot is a versatile appliance capable of performing a wide range of functions including mixing, chopping, crushing, grinding, kneading, whisking, and steaming. It integrates a scale for precise ingredient measurement and a turbo function for maximum speed. The device is designed for domestic use and aims to simplify cooking processes through its various features and programs.

Important Technical Specifications:

Power Supply: 220-240V ~ 50-60Hz
Engine Power: 550W
Motor Power + Heating: 1200W
Maximum Weight Capacity: 5000g
Weight Precision: d=1g
Jug Capacity:
- Mark II: about 2 liters (Max for all "cold" recipes without temperature option)
- Middle mark: approximately 1.5 liters (Max for all "hot" recipes with temperature option)
- Mark I: around 1 Litre
- Lower mark: around 0.5L
Temperature Range: Room temperature to 120 °C (in 10°C intervals)
Speed Settings: 1 to 10 (Speeds 1-4 for butterfly accessory and blade cover, speeds 1-10 for blades)
Time Settings: 10 seconds to 99 minutes (in 30-second intervals)
Wi-Fi Connectivity: 2.4GHz frequency required for "Tuya Smart" application.
Safety Features: Lid safety lock, blade safety lock, non-slip suction cups, automatic shutdown for incorrect jar/lid placement, overheating protection, and warnings for hot surfaces.

Usage Features:

The JOCCA kitchen robot offers both manual control and automatic programs.

Manual Control:

Time Adjustment: Users can set the cooking or preparation duration from 10 seconds to 99 minutes using the TIME button and +/- buttons.
Temperature Adjustment: The temperature can be adjusted from room temperature up to 120°C in 10°C intervals using the TEMP button and +/- buttons. Speeds are automatically locked at level 4 when the temperature exceeds 60°C.
Speed Adjustment: Speed levels from 1 to 10 can be selected using the SPEED button and +/- buttons. Specific speed ranges apply for different accessories (1-4 for butterfly accessory/blade cover, 1-10 for blades).
Scale Function: The integrated scale allows weighing ingredients up to 5kg with 1g precision. The WEIGHT button activates the scale, and a tare function is available to reset the weight to zero.
TURBO Function: This function provides maximum speed for express use, but it should not be used with the butterfly accessory or blade cover, and only when the jug temperature is below 60°C.
Start/Pause: A dedicated button allows starting and pausing programs.

Automatic Programs:

The robot comes with 10 preset automatic programs for common tasks:

Intensive cleaning: 6 min 30 s, Speed 1, 90 °C
Whisk (egg whites, etc.): 2 min, Speed 4
Chop: 8 s, Speed 6
Crush: 12 s, Speed 7
Grind (icing sugar, parmesan, etc.): 10 s, Speed 10
Mixer: 15 s, Speed 6
Knead: 1 min, Speed 2
External steam (fish, steamed vegetables): 30 min, Speed 2, 100 °C
Internal steam (vegetables): 15 min, Speed 2, 100 °C
Crushed ice: 20 s, Speed 7

To access these programs, the AUTO button must be long-pressed, then the desired program selected with +/- buttons, and started with the Start button.

Wi-Fi Connectivity (Tuya Smart Application):

The device can be connected to Wi-Fi (2.4GHz frequency) and controlled via the "Tuya Smart" application. This allows users to:

Add the appliance to their smart home system.
Select recipes from the app.
Prepare ingredients following app instructions.
Pause programs remotely.
The Wi-Fi function can be turned off by holding down the Wi-Fi button for a few seconds.

Accessories:

The robot includes several accessories to enhance its functionality:

Dosing cap (1): Used to cover the jug and measure ingredients (80-100ml).
Lid (2) and Lid gasket (3): For sealing the jug.
Blades (4) and Blade gasket (5): For chopping, crushing, and mixing.
Stainless steel measuring jug (6): The main container for food preparation.
Blade safety lock (7): Ensures blades are securely in place.
Spatula (15): For mixing ingredients when the robot is stopped.
Steam basket (12), Transparent lid steamer (16), Steam tray (17), Steamer basket (18): For steam cooking.
Butterfly accessory (13): For emulsifying foods like cream, egg whites, or mayonnaise (use with slow speeds 1-4, not with Turbo).
Blade covers (14): For mixing without cutting (use with slow speeds 1-4, not with Turbo).

Maintenance Features:

Cleaning: Before first use and after each use, the product should be cleaned with soap and water. The motor base should be cleaned with a soft, slightly damp cloth and should not be immersed in water. All accessories are dishwasher safe.
Intensive Cleaning Program: Program 1 is specifically designed for thorough cleaning of the jar and lid, using water, dishwashing detergent, and cleaning vinegar.
Cooling: A pause time between programs is recommended to allow the robot to cool down.
Ventilation: Ensure ventilation slots are not obstructed to prevent overheating.
Storage: Store the appliance in a safe place.
Troubleshooting: The manual provides a detailed troubleshooting guide for common issues such as the robot not turning on, error codes (E01, E03), liquid presence, and function failures.
Recycling: The product should be disposed of at a designated waste collection point at the end of its useful life, in accordance with the 2012/19/EU WEEE directive.
