CONTROL PANEL
MODE Button (MODO)
Press this button to select among the modes of
cooling, dehumidifying, fan only, or heating.
FAN Button (VENTOINHA)
Press this button to select the desired fan
speed.
ON/OFF Button
(LIGA/DESL.)
Press this button to turn the unit on or off.
TEMPERATURE Button
(TEMPERATURA)
To adjust the temperature, press the
TEMPERATURE buttons one or 5 more times
until the required temperature is reached
SWING Button (OSCILAR)
Press this button to oscillate the louvers or stop
oscillation.
TIMER Button
(TEMPORIZADOR)
To set the operating time, press the ON TIMER
button one or more times until the required time
is displayed.
WATER FULL light
(DEPOSITO CHEIO)
When the water container is full, the unit
automatically stops, the warning light will flash to
signal that the container must be emptied.
Remote control receptor
