REMOVING THE DOOR FROM OVEN (OPTIONAL)
Removable door allows full access to entire interior
of the oven for easier and quicker maintenance.
1. To remove the door, open the door to the maximum angle.
Then pull the buckle at the door hinge backward.
2. Close the door to an angle approximately 30°C. Hold the door
with one hand on each side. Lift and slowly pull out the oven
3. Open the door swing bracket assembly, see the action on the
4. Lift the outer door glass and pull it out, then remove the
middle door glass in the dissemble process.
Do not use force when removing the door and avoid breaking the
glass during the disassembly process.
Hinge springs can come loose and cause personal injury.
Do not lift or carry the oven door by the door hinge.
