Technical Specification
Input impedances Mic: 1.2kohm; Line: 20kohm
Pre-amp overall gain 0dB to 60dB
Common mode rejection 70dB
Equivalent input noise -128.5dBu (unweighted)
Distortion 0.001%
(below Compressor threshold)
Frequency response 10Hz to 70kHz (-3dB)
Maximum input before clipping Mic: +19.5dBu; Line: +44.5dBu
Headroom before clipping +19.5dBu
Compressor threshold -6dBu to +20dBu (variable)
Compressor ratio 5:1 (typical)
Compressor attack time 1 msec to 100 msec (adaptive)
Compressor release time 0.1 sec to 3 sec (adaptive)
Nominal output levels +4dBu/-10dBv
Output impedance 75ohm
Output Level switch 12dB attenuation
Noise Floor -85dBu (typical, with ~40dB mic gain)
VU Meter 8 segment bargraph
Power supply 12V ac mains adaptor
Power consumption 12W
Mechanical 220W x 44H x 180D (overall)
Weight 1 kilo
14
Troubleshooting
1) No Power (no lights work)
• Is the power supply plugged in (both ends)?
• Is the mains power on?
2) The microphone doesn’t work
• Is it connected to the correct (XLR) input on the rear panel?
• If it is a condenser microphone, is the phantom power switched on?
• Is the ‘Line’ switch out (LED off)?
• Is the ‘Input Gain’ control turned up?
• Is the ‘Output Gain’ control turned up?
3) The line input doesn’t work
• Is the source connected to the correct (jack) input on the back of the unit?
• Is the ‘Line’ switch in (LED on)?
• Is the ‘Input Gain’ control turned up?
• Is the ‘Output Gain’ control turned up?
4) The compressor doesn’t work
• Is the ‘Comp’ switch in (LED on)?
• Is the ‘Compress’ control turned up enough?
• Is there enough signal, as set by the ‘Input Gain’ control, to drive the
compressor?
5) Too little or too much compression
• Turn the ‘Input Gain’ control up or down respectively, to adjust the
signal level to the compressor
6) The Meequalizer doesn’t ‘t work.
• Is the ‘EQ’ switch in (LED on)?
• Is ‘Input Gain’ control turned up?
• Is ‘Output Gain’ control turned up?
7) Too much noise
• Is the ‘Input Gain’ control too high? Try moving the mic closer to the
source
• Is the ‘Output Gain’ control too high (eg: when lots of compression is
being used)?
• Is there too much EQ boost?
• Is the noise already present in the input signal? (Try removing the
input)
8) Sounds distorted
• Is the ‘Input Gain’ control too high?
• Is the ‘Output Gain’ control too high?
• Is there too much EQ boost?
• When using the compressor, is the Release control set too low?
