MNP64ENV00 Date: 03-2007 Rev. 03 Page 12 of 16
F In tolerance programming NO EXIT CODES ARE GENERATED for
recognised coins, so the selector should be moved away from its normal
location in the machine so the coins are not sent to the machine vault, as they
will not be accounted for and so on.
5.2. Recording a new coin.
The T15 Selector allows you to program and delete a new coin using the switches.
5.2.1. Recording a coin using switches.
è The procedure is as follows:
1. Disconnect the selector (remove the connecting cable) or turn off the
machine that provides the selector with its power supply.
2. Move switches 1, 2, 3 and 4 to the ON position.
3. Apply the power supply (connect the connecting cable or turn the machine
on).
4. Move switch 3 to the OFF position.
5. Move switch 2 to the OFF position.
6. Move switch 1 to the OFF position.
7. You will now be in new coin programming mode and you now have three
alternatives:
a) Programming a new coin: Move switch 1 to the ON position.
When you insert the first coin, the selector will initialise the
parameter area and will only program read parameters. Put the
type of coin to be programmed through several times
(recommended procedure).
b) Extending the programming of a coin that had already been
programmed using the above procedure: Move switch 1 to the
OFF position. When you put the coins through, parameters in
memory will not be deleted and the parameters obtained from the
coins will extend those existing in memory. (procedure for
extending parameters)
c) Deleting a coin that had been programmed using the above
procedure: Move switch 1 to the ON position but do not insert
any coins. Move switch 4 to the OFF position. The selector will
delete all parameters in the switch programming area (procedure
to delete any existing programming). The selector will move
the acceptance electromagnet twice.
8. To exit programming mode in cases a) and b), move all switches to the OFF
position. When you move switch 4 the selector will move the acceptance
electromagnet twice.
The following table summarises the above.
SWITCHES
1 2 3 4
COIN PROGRAMMING
ON OFF OFF ON Programs inserted coins.
OFF OFF OFF ON Extends memory parameters of
inserted coins.
ON OFF OFF ON Without inserting coins, when you
