Control panel
1 10 122 4 5 6 7 8 9 113
1. Programme dial
2. On/Off button
3. Programme indicators
4. Dry plus button
5. Reverse plus button
6. Anti-crease button
7. Alarm button
8. Time dry button
9. Delay start button
10. Display
11. Start/Pause button
12. Indicators:
Tank - drain the water container
Filter - clean the filter
Condenser - check the condenser
Display
default laundry dryness
moderate laundry dry-
ness
maximum laundry dry-
ness
reverse plus option acti-
vated
m / m
anti-crease phase dura-
tion
drying phase indicator
cooling phase indicator
anti-crease phase indica-
tor
child lock activated
delay start activated
