Johnson Controls DP2500-R8 User Manual

English
IS_DP2500-R8 Rev. A_11 2009
This document is subject to change without notice 3
Technical Specifications
Response Time 0.8 / 4 s selectable push button
Accuracy ±1,5% or (±6 Pa < 250 Pa) of selected pressure range
Bursting pressure 30 kPa
Suitable media Air and non-aggressive gases
Measuring element Piezoresistive
Electrical interface (3-wire)
- Supply voltage 24 VAC or VDC
- Max. tolerance ±10%
- Power consumption <1.0 W (<1.5W with Iout 20 mA)
- Output signal 0…10 VDC, Load R minimum 1kΩ or
4…20 mA, maximum load 500Ω
Materials
- Housing ABS
- Cover PC
- Pressure connections ABS
- Duct connectors ABS
- Tubing PVC, soft
Connections
- Electrical connections 4 screw terminals, max 1.5 mm
2
- Cable entry M16
- Pressure connections Male ∅ 5,0 mm and 6,3 mm
Weight 150 grams, with accessories 290 grams
Dimensions 90,0 x 71,5 x 36,0 mm
General ambient condition
Temperature range
- Operation -10…+50 °C (-5…+50 °C for -AZ model)
- Storage -20…+70 °C
- Ambient humidity 0 to 95% RH
Safety
- Protection standard IP54
- Conformance Meets the requirements for CE marking:
EMC directive 2004/108/EC
Rohs Directive 2002/95/EY

Johnson Controls DP2500-R8 Specifications

General

Brand	Johnson Controls
Model	DP2500-R8
Category	Transmitter
Language	English
