Johnson Controls GCGD12 - Page 5

400038-UTG-B-0708
Johnson Controls Unitary Products 5
— = Not applicable.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL W
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH MA
GCGD18S21S2
MA08B 17 FC/MC18B 600 18.0 12.6 13.00 11.00
MA08B 17 FC/MC24B 600 18.0 12.6 13.00 11.00
GCGD24S21S2
MA08B 17 FC/MC35B 800 24.0 17.2 13.00 11.00
MA08B 17 FC/MC36B 800 24.0 17.2 13.00 11.00
MA08B 17 FC/MC43B 800 24.0 17.2 13.00 11.00
GCGD30S21S2
MA12B 17 FC/MC35B 1000 29.0 21.2 13.00 11.00
MA12B 17 FC/MC43B 1000 29.0 21.2 13.00 11.00
GCGD36S21S2
MA12B 17 FC/MC43B 1200 35.0 24.4 13.00 11.00
MA14D 24 FC/MC48D 1200 35.0 24.4 13.00 11.00
GCGD42S21S2
MA16C 21 FC/MC43C 1400 42.0 29.4 13.00 11.00
MA14D 24 FC/MC48D 1400 42.0 29.4 13.00 11.00
MA16C 21 FC/MC48C 1400 42.0 29.4 13.00 11.00
GCGD48S21S2
MA16C 21 FC/MC48C 1600 46.0 32.6 13.00 11.00
MA20D 24 FC/MC48D 1600 46.0 32.6 13.00 11.00
GCGD60S21S2 MA20D 24 FC/MC62D 1800 54.0 41.5 13.00 11.00
13 SEER AC WITH AHP / SHP / F*FP
GCGD12S21S2 AHP18 17 –
450 12.0 8.9 13.00 11.00
GCGD18S21S2
AHP18 17 –
650 18.0 12.6 13.00 11.00
AHP24 17 –
650 18.0 12.6 13.00 11.00
F4FP024 18 –
600 18.0 12.6 1300 11.00
GCGD24S21S2
AHP30 17 –
795 24.0 17.3 13.00 11.00
F4FP036 21.5 –
860 24.0 17.3 13.00 11.00
GCGD30S21S2
AHP30 17 –
1015 29.0 21.2 13.00 11.00
AHP36 21 –
1015 29.0 21.2 13.00 11.00
F4FP040 21.5 –
1000 29.0 21.2 13.00 11.00
GCGD36S21S2
AHP36 21 –
1235 35.0 24.4 13.00 11.00
F5FP048 24 –
1235 35.0 24.4 13.00 11.00
GCGD42S21S2
AHP42 21 –
1485 42.0 29.4 13.00 11.00
F5FP048 24 –
1455 42.0 29.4 13.00 11.00
GCGD48S21S2
AHP/SHP60 24 –
1600 46.0 33.0 13.00 11.00
F5FP048 24 –
1690 46.0 33.0 13.00 11.00
F5FP060 24 –
1680 46.0 33.0 13.00 11.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
