Johnson Controls GVD Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
104
BACnet
Attributes
Object
Type
Object
ID
Read/
Write
Short Description
Long
Description
Point Denitions (Units)
C2B-RunTime AV 29948 R C2B-RunTime
Compressor
Accumulated
Runtime 2B
Displays the total runtime for
compressor 2B (hours)
C2B-Starts AV 29950 R C2B-Starts
Compressor
Number Times
ON 2B
Displays the compressor 2B start
count
ClgCapLim AV 29964 R/W ClgCapLim
Cooling Capacity
Limit
A BAS command to adjust the
cooling capacity limit (0–100%)
CoastTime AV 29966 R/W CoastTime Coast Time
A BAS command for unit to operate
in coast mode (0–120 minutes)
DATCapAlmOffset AV 29967 R/W DATCapAlmOffset
DAT Capability
Alarm Offset
A BAS command to adjust alarm
for DAT difference from setpoint
(1.0–10.0°F)
EAHR-T AV 29970 R EAHR-T
Exhaust Air Heat
Recovery Temp
Displays the exhaust air energy
recovery temperature (°F)
EF-Flow AV 29971 R EF-Flow
Exhaust Flow
Value
Displays the return airow (CFM)
FFILT-DP AV 29972 R FFILT-DP
Final Filter
Differential
Pressure
Displays the nal lter differential
pressure (iwg)
H1-Starts AV 29973 R H1-Starts
Heating Number
Times ON 1
Displays the heating start counts for
stage 1
H2-Starts AV 29974 R H2-Starts
Heating Number
Times ON 2
Displays the heating start counts for
stage 2
H3-Starts AV 29975 R H3-Starts
Heating Number
Times ON 3
Displays the heating start counts for
stage 3
H4-Runtime AV 29977 R H4-Runtime
Heating Stage
4 Accumulated
Runtime
Displays the total runtime for stage 4
heating (hours)
H4-Starts AV 29979 R H4-Starts
Heating Number
Times ON 4
Displays the heating start counts for
stage 4
H5-Runtime AV 29981 R H5-Runtime
Heating Stage
5 Accumulated
Runtime
Displays the total runtime for stage 5
heating (hours)
H5-Starts AV 29983 R H5-Starts
Heating Number
Times ON 5
Displays the heating start counts for
stage 5
H6-Runtime AV 29985 R H6-Runtime
Heating Stage
6 Accumulated
Runtime
Displays the total runtime for stage 6
heating (hours)
H6-Starts AV 29987 R H6-Starts
Heating Number
Times ON 6
Displays the heating start counts for
stage 6
H7-Runtime AV 29989 R H7-Runtime
Heating Stage
7 Accumulated
Runtime
Displays the total runtime for stage 7
heating (hours)
H7-Starts AV 29991 R H7-Starts
Heating Number
Times ON 7
Displays the heating start counts for
stage 7
H8-Runtime AV 29993 R H8-Runtime
Heating Stage
8 Accumulated
Runtime
Displays the total runtime for stage 8
heating (hours)
Table 32: BACnet Points List (Continued)
