Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
87
Operation
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
MZ VAV >
Service
Htg-S (Heating Status)
OFF-Idle, ON, SAT Tempering, Morning Warm-
Up, Thermostat Heating, Unoccupied Heating,
Occupied Heating, OFF-Disabled, OFF-OAT
Lockout, OFF-SAT Limit, OFF-Waiting for
Changeover Delay, Comfort Ventilation
H1 (Heating Stage Command 1) OFF, ON
H2 (Heating Stage Command 2) OFF, ON
H3 (Heating Stage Command 3) OFF, ON
H4 (Heating Stage Command 4) OFF, ON
H5 (Heating Stage Command 5) OFF, ON
H6 (Heating Stage Command 6) OFF, ON
H7 (Heating Stage Command 7) OFF, ON
H8 (Heating Stage Command 8) OFF, ON
VAV Box (MZVAV Box Heat Command) OFF, ON
SZVAV >
Setup
SZVAVFanOnlyFanSpd (SZVAV Fan
Only Fan Speed)
% (20–100)
SZVAVMinFanSpd (SZVAV Minimum
Fan Speed)
% (20–67)
SZVAVClgMinFan (SZVAV Cooling
Minimum Fan Speed)
% (20–67)
SZVAVHtgMinFan (SZVAV Heating
Minimum Fan Speed)
% (20–100)
SZVAV >
Service
StgClgCmd (Staged Cooling Command) %
StgHtgCmd (Staged Heating Command) %
OprZT (Operational Zone Temperature) deg F
DAT (Discharge Air Temperature) deg F
SF-O (Fan % Command) %
Econ (Economizer Damper % Command) %
C1A (Compressor 1A Command) OFF, ON
C1B (Compressor 1B Command) OFF, ON
C2A (Compressor 2A Command) OFF, ON
C2B (Compressor 2B Command) OFF, ON
H1 (Heating Stage Command 1) OFF, ON
H2 (Heating Stage Command 2) OFF, ON
H3 (Heating Stage Command 3) OFF, ON
H4 (Heating Stage Command 4) OFF, ON
H5 (Heating Stage Command 5) OFF, ON
H6 (Heating Stage Command 6) OFF, ON
H7 (Heating Stage Command 7) OFF, ON
H8 (Heating Stage Command 8) OFF, ON
Humidity >
Setup
HGR-En (Hot Gas Reheat Enabled For
Operation)
None, Normal, Alternate
Dehum-SP (Dehumidication Setpoint) %RH (0–100)
HGRUnocc-En (HGRH Enabled for
Unoccupied Operation)
No, Yes
Table 26: Menus and Submenus (Continued)
