Table 4: JC-RTR11002-0 BACnet Router technical specification
Specification Description
Network and serial interfaces One Ethernet port: 100/10 Mbps, 8-pin RJ45 connector
One FC port: RJ12 6-pin port, connects with 1.5 m (4.9 ft) RJ12 field bus cable
One galvanically isolated RS-485 port, with a removable 4-pin terminal block
Three USB ports: one Micro-B port and two USB A ports. All USB ports are
currently inactive.
Transmission speeds Ethernet communication: 100 Mbps or 10 Mbps
The device can reside and interoperate on a 1 Gbps network, but does not itself
connect at 1 Gbps.
Galvanically isolated, serial communication (FC bus): 76,800 bps, 38,400 bps,
19,200 bps, 9600 bps, or 1200 bps (selectable)
Ambient temperature conditions Operating: 0°C to 50°C (32°F to 122°F)
Non-Operating: -40°C to 70°C (-40°F to 158°F)
Ambient humidity conditions Storage: 5% to 95% RH, 30°C (86°F) maximum dew point conditions
Operating: 10% to 90% RH, 30°C (86°F) maximum dew point conditions
Housing Black polycarbonate and acrylonitrile butadiene styrene (ABS) blend
IP protection class: IP20
UL flammability rating: UL94-5VB
Mounting On flat surface with screws on three mounting clips or a single 35 mm DIN rail
Dimensions (height x width x depth) 190 mm x 125 mm x 44.5 mm (7.48 in. x 4.92 in. x 1.75 in.)
Weight 0.387 kg (0.852 lbs)
Compliance
Note: This compliance applies to
the JC-RTR11002-0 BACnet Router
only. For Control Panel Assembly,
you must adhere to local regu-
lations and compliance require-
ments for your application.
United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment; FCC Compliant to CFR47, Part 15, Subpart B, Class A, Conformance
to FIPS 140-2 Level 1 using FIPS validated components.
Canada: UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal
Equipment; Industry Canada Compliant, ICES-003
Europe: CE Mark – Johnson Controls, Inc. declares that this product is in
compliance with the essential requirements and other relevant provisions of
the EMC Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet Testing Laboratories™ (BTL) Listing Pending
FIPS 140-2 Level 1: Compliant using FIPS validated components
United Kingdom: Johnson Controls declares that this product is in compliance
with Electromagnetic Compatibility Regulations, The Electrical Equipment
(Safety) Regulations, and Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment Regulations.
Table 5: JC-RTR11002-0 BACnet Router Standard Control Panel Assembly technical specifications
Specification Description
Part number P2ABN-JB001NA3
Enclosure rating NEMA 1
Enclosure finish ANSI 61 gray polyester powder coating
Ambient operating condition 0°C to 50°C (32°F to 122°F)
10% to 90% RH
30°C (86°F) maximum dew point conditions
JC-RTR11002-0 BACnet Router Installation Guide 11
