Metasys Integrator® MIG3500 Series Installation Instructions 9
Technical Specifications
Table 5: MIG3500 Accessories Ordering Information
Product Code
Number
Description
Y65T31-0 Power transformer (Class 2, 24 VAC, 40 VA maximum output), no enclosure
AS-XFR050-0
Power transformer (Class 2, 24 VAC, 50 VA maximum output), no enclosure
EN-EWC25-0 Standard enclosure with dimensions: 406 x 406 x 190 mm (16 x 16 x 7.5 in.)
MM-CVT101-0 RS232 to RS485 Converter (old style)
AS-CVTPRO300-1 Zone Bus/N2 Bus Interface Converter with 120 VAC/3 VDC External Power Adapter (North American
version)
IU-9100-8401 RS232 to RS485 Interface Unit (European use only)
MIG3500 Model
Power Requirement Dedicated nominal 24 VAC, Class 2 power supply (North America), Safety Extra-Low
Voltage (SELV) power supply (Europe), at 50/60 Hz (20 VAC minimum to 30 VAC
maximum)
Power Consumption 25 VA maximum
Ambient Operating Temperature 0 to 50°C (32 to 122°F)
Ambient Operating Conditions 10 to 90% RH, 30°C (86°F) maximum dew point
Ambient Storage Temperature -40 to 70°C (-40 to 158°F)
Ambient Storage Conditions 5 to 95% RH, 30°C (86°F) maximum dew point
Battery Non-rechargeable lithium 3.0 V, 160 mAh; typical life of 5 to 7 years at 21°C (70°F)
Panasonic® CR2025 or equivalent
Processor 192 MHz Renesas™ SH4 7760 RISC processor
Memory 128 MB Flash nonvolatile memory
128 MB Synchronous Dynamic Random Access Memory (SDRAM)
Operating System Microsoft® Windows® CE embedded
Network and Serial Interfaces One Ethernet port; 10/100 Mb/s; 8-pin RJ-45 connector
One optically isolated RS-485 port; 9600 bps; pluggable and keyed 4-position terminal
block
Two RS232C serial ports with standard 9-pin sub-D connectors that support standard
baud rates.
Dimensions
(Height x Width x Depth)
131 x 270 x 62 mm (5.2 x 10.6 x 2.5 in.)
Minimum space for mounting: 210 x 350 x 110 mm (8.3 x 13.8 x 4.3 in.)
Housing Plastic housing material: ABS + polycarbonate; Protection: IP20 (IEC60529)
Mounting On flat surface with screws on three mounting clips or a single 35 mm DIN rail
Shipping Weight 1.2 kg (2.7 lb)
Compliance United States
UL Listed (PAZX), UL 916
FCC compliant, CFR47, Part 15, Class B
Canada
UL Listed (PAZX7), CAN/CSA C22.2 No. 205
Industry Canada compliant
Europe
EMC Directive, 89/336/EEC
Australia/New Zealand
C-Tick mark compliant
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these
specifications, consult the local Johnson Controls® office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication
or misuse of its products.
