VAV Controller—Variable Air Volume (VAV) Controller 31
Table 6: VAV100/101 Terminal Identification
Series 100/101 Controller
Terminal Description Terminal Description
AI COM
Analog Input
Common
AI 1
Analog Input 1
AI COM
Analog Input
Common
AI 2
Analog Input 2
AI COM
Analog Input
Common
AI 3
Analog Input 3
AI COM
Analog Input
Common
AI 4
Analog Input 4
AI COM
Analog Input
Common
AI 5
Analog Input 5
AI COM
Analog Input
Common
AI 6
Analog Input 6
+15 VDC
+15 Volts DC
+15 VDC
+15 Volts DC
BI CM
Binary Input
Common
BI 1
Binary Input 1
BI CM
Binary Input
Common
BI 2
Binary Input 2
BI CM
Binary Input
Common
BI 3
Binary Input 3
BI CM
Binary Input
Common
BI 4
Binary Input 4
24 VAC POWER
Transformer High
Side
24 VAC COMMON
Transformer Low
Side
ZBUS
Zone Bus
AREF
N2 Reference and
ZBus Common
N2A+
N2 Bus +
N2A–
N2 Bus –
24 VAC
24 Volts AC
BO 1
Binary Output 1
24 VAC
24 Volts AC
BO 2
Binary Output 2
24 VAC
24 Volts AC
BO 3
Binary Output 3
24 VAC
24 Volts AC
BO 4
Binary Output 4
24 VAC
24 Volts AC
BO 5
Binary Output 5
24 VAC
24 Volts AC
BO 6
Binary Output 6
24 VAC/AOCM*
24 Volts AC/
AO Common
BO 7/AO 1*
Binary Output 7/
Analog Output 1
24 VAC/AOCM**
24 Volts AC/
AO Common
BO 8/AO 2**
Binary Output 8/
Analog Output 2
*
VAV100 has eight BOs.
**
VAV101 has six BOs and two AOs.
