VAV Controller—Variable Air Volume (VAV) Controller 51
72F73F74FApplication Examples
The following examples are created by answering configuration questions
using HVAC PRO for Windows to identify terminal locations of the inputs
and outputs. Refer to the HVAC PRO for Windows User’s Manual (FAN
637.5), the VAV Controller section, for detailed information regarding
controller configuration.
Single Duct
Applications
