VAV Controller—Variable Air Volume (VAV) Controller 33
Table 7: VAV 110/111 Terminal Identification
Series 110/111 Controller
Terminal Description Terminal Description
AI CM
Analog Input
Common
AI 1
Analog Input 1
AI CM
Analog Input
Common
AI 2
Analog Input 2
AI CM
Analog Input
Common
AI 3
Analog Input 3
AI CM
Analog Input
Common
AI 4
Analog Input 4
AI CM
Analog Input
Common
AI 5
Analog Input 5
AI CM
Analog Input
Common
AI 6
Analog Input 6
+15 VDC
+15 Volts DC
+15 VDC
+15 Volts DC
BI CM
Binary Input
Common
BI 1
Binary Input 1
BI CM
Binary Input
Common
BI 2
Binary Input 2
BI CM
Binary Input
Common
BI 3
Binary Input 3
BI CM
Binary Input
Common
BI 4
Binary Input 4
24 VAC POWER
Transformer High
Side
COMMON
Transformer Low
Side
ZBUS
Zone Bus
REF
N2 Reference
N2-
N2 Bus -
N2+
N2 Bus +
24 VAC
24 Volts AC
BO 1
Binary Output 1
24 VAC
24 Volts AC
BO 2
Binary Output 2
24 VAC
24 Volts AC
BO 3
Binary Output 3
24 VAC
24 Volts AC
BO 4
Binary Output 4
24 VAC
24 Volts AC
BO 5
Binary Output 5
24 VAC
24 Volts AC
BO 6
Binary Output 6
24 VAC/AO CM
24 Volts AC/AO
Common
BO 7/AO 1
Binary Output 7/
Analog Output 1
24 VAC/AO CM
24 Volts AC/AO
Common
BO 8/AO 2
Binary Output 8/
Analog Output 2
