86 VAV Controller—Variable Air Volume Controller
Table 40: Damper/Actuator Code Numbers
Code Number Description
EDA-2040-21 or -22
2-minute Rotation Time 24 VAC Incremental
EDA-2040-61 or -62
6-minute Rotation Time 24 VAC Incremental
ATP-2040-212
EDA-2040-1 and DPT-2015-1 with
Cable
24 VAC Incremental
1 to 5 VDC Transmitter
ATP-2040-612
EDA-2040-2 and DPT-2015-1 with
Cable
24 VAC Incremental
1 to 5 VDC Transmitter
M100C Series
Zone Bus Damper Actuators Zone Bus Addressable
M9000-500 Series
Valve Linkage Assembly for M9100
and M9200 Direct Mount Actuators
M9100-G Series
Direct Mount Actuators Proportional - Voltage or
Current
M9100-H Series
Direct Mount Actuators Proportional - Voltage or
Current
M9200-G Series
Direct Mount Actuators Proportional - Voltage or
Current
M9200-H Series
Direct Mount Actuators Proportional - Voltage or
Current
Table 41: Valve Actuator Code Numbers
Code Number Description Type
VA-715x Series
Valve Actuator Incremental or
0-10 VDC Proportional
VA-7200 Series
Valve Actuator Incremental or
0-10 VDC Proportional
VA-8020 Series
Valve Actuator Assemblies 1/2 in. 24 VAC
Triac/Incremental
VA-8022 Series
Valve Actuator Assemblies 1/2 in. 0-10 VDC
VA-8050 Series
Valve Actuator Assemblies
1/2 in., 3/4 in., 1 in., and 1-1/2 in.
"
24 VAC
Triac/Incremental
VA-8051 Series
Valve Actuator Assemblies
1/2 in., 3/4 in., 1 in., and 1-1/2 in.
"
24 VAC
Triac/Incremental/ with
Feedback
VA-8052 Series
Valve Actuator Assemblies
1/2 in., 3/4 in., 1 in., and 1-1/2 in.
"
0-10 VDC
VG-5000 Series
Valve/Actuator Assemblies
1/2 in., 3/4 in., and 1 in.
24 VAC On/Off
Incremental 0-10 VDC
EP-8000-1
and -2
Electric to Pneumatic Transducer
for Pneumatic Valves
0 to 10 VDC to
Pneumatic High or Low
Volume
Damper Actuator
Assemblies
Valve Actuator
Assemblies
